Description
Product Highlights
- 54-inch 10-gauge-steel fabricated deck with 7-gauge top and bottom reinforcements for added durability
- Commercial-grade electric-start18.5 hp Kawasaki engine (603cc)
- Hand-lever steering control with ball bearing linkage for smooth handling
Product Specifications
Engine
- Engine Brand:Kawasaki
- Engine Model:FS Series
- Engine Model Number:600V
- Engine Displacement:603cc
- Engine Output: 18.5HP
- Fuel Tank Capacity:5 gal. US (18.9 L)
- Cylinders:Twin
- Engine Start:Ignition Key
- Engine Oil Capacity:2.0 qt. US (1.89 L)
- Lubrication:Fully pressurized
- Charging System:15 amp regulated
- Fuel Gauge:No
- Choke:Separate Choke
- Air Filter:High Density
- Oil Filter:Yes
- Fuel Delivery:Carburetor
Drive System
- Transmission:Hydro-Gear ZT 2800 charged (commercial-grade)
- Forward Speed:7 mph / 11.3 km/h
- Reverse Speed:3 mph / 4.8 km/h
Cutting Deck
- Deck Cutting Width:54 in
- Deck Material:Fabricated
- Deck Construction:Fixed floating, fabricated 10ga. (.135) steel shell
- Spindle Construction:5″ sealed cast aluminum housing (maintenance-free)
- Blade(s):3 high-lift Marbain blades / 18,500 fpm (approx.)
- Cutting Height Range:1.5″ – 4.5″
- Anti-Scalping:2 front deck gauge wheels
- Deck Positions:4-pin manual with deck-mounted lift handles / 7 positions
Warranty
- Warranty:2 year / no-hour-limit commercial warranty
- Commercial Warranty:2 year / no-hour-limit commercial warranty
Chassis
- Frame:Operator Tower with 7ga. Construction, 1.5 x 3″ fully welded tube
- Front Axle:Frame-mounted foot pedal front-end lift assist
Controls
- Cruise Control:Single-lever cruise control (0-7 MPH)
- Brakes:Hand-operated lever
- Steering Control:Hand-lever steering control with ball bearing linkage for smooth feel
Wheels
- Rear Tires:18×8.5-8
- Front Tires:11×4-5 RF
- Tire Tread:Turf Master
Dimensions
- Dimensions L/W/H:77″ x 50″/61″ x 46″
- Weight (approx.):665 lbs
Additional Specifications
- Hour Meter:Basic Hour Meter (no tach)
- Discharge Chute:High-density, impact-resistant rubber
- Model Number:55RI6HNV050
