Technical Data:
- Operating Weight 980 kg
- Bucket Capacity 0.03 m
- Max Digging Depth 1,693 mm
- Max Digging Height 2,560 mm
- Max Dumping Height 1,800 mm
- Min Swing Radius 3,060 mm
- Max Climbing Angle 15
- Travel Speed 01.8 km/h
Engine:
- Engine Model RATO Gasoline Engine
- Rated Power 23 hp (16.8 kW)
- Fuel Type Gasoline (92)
- Fuel Tank Capacity 6.6 L
Hydraulics:
- Hydraulic Pump Type Gear Pump (GP510803)
- Hydraulic Flow 21.6 L/min
- System Pressure 25 MPa
- Auxiliary Hydraulic Thumb Standard
- Multi-Circuit Valve 4 Mechanical + 4 Hydraulic
- Rotary Hydraulic Motor BM2-315
- Traveling Hydraulic Motor BM6-315
Dimensions:
- Overall Length 2,925 mm
- Overall Width 958 mm
- Overall Height 2,422 mm
